Description
Product selling points:
- Suitable for amplifying signal blind spots in various indoor locations such as conference halls, hotels, and the lower floors of large buildings.
- Expand the coverage area of the base station signal.
- Enhance the coverage range for transmitting and receiving mobile signals.
- Reduce radiation exposure to the human body from mobile phones.
- Prolong the usage time and lifespan of mobile phone batteries.
- Easy and flexible installation, adaptable to specific scenarios.
- Environmentally friendly, compact in size, and cost-effective.
- Full duplex operation with high isolation between uplink and downlink.
- Economically reasonable coverage solutions with high antenna isolation, preventing interference between transmission and reception.
- Minimal outdoor signal spillage, not affecting the sensitivity of base station reception.
- Designed with an aluminum alloy casing for aesthetics, durability, and excellent performance.
Specification for N78 5G Signal Booster
| Model | WK-5GN78-20 | |
| Parameter Data | Up Link | Down Link |
| Frequency Range(MHz) | 3400-3600 | 3400-3600 |
| Max. Gain(dB) | 65 | |
| Max. Output Power(dBm) | 20 | |
| VSWR | ≤2.0 | |
| RF Connector | N (F) | |
| Working Voltage | DC12V | |
| Working Current | <2A | |
| Input Voltage | AC100~240V，50-60Hz | |
| Dimension | 189*96*21mm | |
| Auto Gain Control(AGC) | ≥25dB | |
| Function | ||
| WIFI Control | Adjust the gain range by using the mobile web page | |
| Signal Analysis | Monitor the signal variation curve from the outdoor connection | |
