Description
Features:
Broadband bandwidth
Long distance coverage
Low VSWR
High gain ,good performance
| Model型号 | WK-PGA-15 | |||
| 技术指标Electrical specifications | ||||
| Frequency range 频率(MHz) | 698-960 | 1710-2700 | 3300-4000 | |
| Bandwidth 带宽(MHz) | 262 | 990 | 700 | |
| Polarization极化方式 | Vertical+Horizontal | |||
| Gain增益(dBi) | 15 | 24 | 30 | |
| Vertical Beamwidth (°)垂直波瓣宽度 | 25 | 14 | 6 | |
| Horizontal Beamwidth (°)水平波瓣宽度 | 23 | 12 | 5 | |
| Impedance阻抗(Ω) | 50 | |||
| VSWR驻波比 | ≤3.0 | |||
| Maximum power最大功率(W) | 100 | |||
| Lightning protection雷电保护 | DC Ground | |||
| 机械指标Mechanical specifications | ||||
| Connector接头型号 | N Female×2 | |||
| Height × width × depth长宽高(mm) | 600×900 | |||
| Antenna weight天线重量(kg) | 3 | |||
| Mounting Mast Diameter-mm | ɸ35-50 | |||
| Rated wind velocity抗风强度(m/s) | 60 | |||
| Reflector material反射面材料 | Aluminum Alloy | |||
| Cable 电缆 | RG58 | |||
| Radome color外罩颜色 | Sliver | |||
| Operating temperature工作温度(℃) | -40～70 | |||
