Description
|
Electrical
|
|
|
Impedance
|
50 ohm
|
|
Frequency
|
DC-3GHz
|
|
VSWR
Insertion Loss
|
≤1.10
≤0.10dB@3GHz
|
|
PIM (@2-tone×20w)
|
≤-155dBC
|
|
Dielectric withstanding voltage
|
≥2500V RMS, 50Hz, at sea level
|
|
Dielectric Resistance
|
≥5000MΩ
|
|
Center contact resistance
|
≤1.0m Ω
|
|
Outer contact resistance
|
≤0.25m Ω
|
|
Mechanical
|
|
|
Mating cycles
|
≥500 times
|
|
Apply with the cable
|
1/2″ super flexible coaxial cable
|
|
Material and plating
|
|
|
Body
|
Brass / Nickel plated
|
|
Center conductor
|
Brass / Gold or silver plated |
| Insulator |
PTFE
|
|
Other
|
Brass / Ni plating
|
|
Environmental
|
|
|
Temperature range
|
-40℃~+85℃
|
|
Watertightness
|
IP67
|
|
Rosh-compliance
|
Full Rosh-compliance
|
|
Salt-fog test
|
96h
|
