| Model 型号 |
WK-BM5G-12 |
| Electrical specifications 技术指标 |
| Frequency range 频率 (MHz) |
690-3800Mhz |
| Polarization 极化方式 |
Horizontal |
| Radiation Direction 辐射方向 |
Omnidirectional |
| Gain 增益 (dBi) |
12 |
| Impedance 阻抗(Ω) |
50 |
| VSWR 驻波比 |
≤2 |
| Maximum input power 最大输入功率 (W) |
50 |
| Lightning protection 雷电保护 |
DC Ground |
| Mechanical specifications 机械指标 |
| Connector 接头 |
N/SMA/TS9/CRC9*2 (customized) |
| Height × width × depth 尺寸 (mm) |
ɸ425×63mm |
| Antenna weight 天线重量 (kg) |
1 |
| Rated wind velocity 抗风强度 (m/s) |
60 |
| Cable 电缆 |
30cm RG58*2 (customized) |
| Radome material 外罩材料 |
ABS |
| Radome color 外罩颜色 |
White |
| Operating temperature 工作温度 (℃) |
-35～70 |
