| Electrical specifications |
| Frequency range (MHz) |
117-137MHz |
| Polarization |
Vertical |
| Gain (dBi) |
5dbi |
| Radiation |
Omni |
| Vertical Beam width 3dB (°) |
80° |
| Impedance (Ω) |
50 |
| VSWR |
≤1.5 |
| Maximum input power (W) |
200 |
| Lightning protection |
DC Ground |
| Mechanical specifications |
| Connector |
N-male |
| Antenna cable |
2*3m LMR400 |
| Antenna height(mm) |
920mm per |
| Antenna weight (kg) |
5 |
| Antenna material |
Aluminum Alloy |
| Mounting hardware material |
Aluminum Alloy clamp+Stainless Steel U bracket |
| Wind Load(km/h) |
160 |
| Ambient temperature |
-40℃~+80 |
| Water ingress rating |
IP65 |
